Power Connect 125 kW / 237 kWh Commercial Battery Storage System — BES-125

The Power Connect BES-125 is a high-capacity commercial battery energy storage system delivering 125 kW output and 237 kWh of storage for demanding commercial and industrial applications.

Integrated into a single enclosure, the BES-125 includes a power conversion system (PCS), battery, battery management system (BMS), MPPT solar controller, and energy management system (EMS). It supports a 1C charge/discharge rate for fast and efficient energy flow.

Power & Capacity
- Output Power: 125 kW continuous / 150 kW maximum
- Battery Capacity: 237 kWh
- Charge/Discharge Rate: 1C
- Cooling: Air cooled
- Noise Level: 58 dBA @ 7m
- Operation: On-grid and off-grid capable
- Voltage: 380 V / 400 V / 415 V, 3-Phase AC

Dimensions & Weight
- L x W x H: 2,350 x 1,100 x 1,750 mm
- Dry Weight: 2,655 kg

Typical Applications
- Commercial and industrial facilities
- Manufacturing plants — smooths power fluctuations and supports start-up loads
- Shopping centres and retail — reduces peak demand charges
- Refrigerated logistics and cold storage — improves power reliability
- Hospitals and healthcare facilities — supports critical loads

Backed by Power Connect Solutions national support network. Contact us to discuss your site requirements and receive a tailored proposal.
